*366 714
KMZ18522-2EL Xtreme Performance 184mm Rigid Ceramic Twin Plate Clutch Kit Incl Flywheel 1220Nm
Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.
New product
Sold out
1.863,00 € tax incl.
Product is unavailable. Please choose other goods.
For automatic information about product status update,
click on "notify me".
click on "notify me".
KMZ18522-2EL
9337467296778
Frequently bought together
Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.
Xtreme Motorsport 200mm twin plateThe Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality.
The 200mm Race Clutch Kits consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).Product Features:
- Torque capacity 1200Nm
- Kit contains everything you need for a successful installation + accessories
- Rigid driven discs (individual hubs)
- Push type billet alloy cover
- 4140 Chromoly pressure & intermediate plates
- Hardened steel wear posts
- Low inertia
- Serviceable components
- SFI certified design
| Clamping Force | 1000kg |
| Torque Rating | 1200Nm |
| Bearing Contact Diameter | 44-52mm |
| Bearing Load (@ 48mm) | 218kg |
| Release Travel Required | 6mm |
| Assembly Mass (without flywheel) | 7kg |
| Disc Set Static Mass | 1.75kg |
| Friction Thickness New | 7mm (0.275") |
| Friction Thickness Worn | 6.48mm (0.255") |
Tech. Info:
Reference: KMZ18522-2EL
Weight: 10.5
Note:
Clutch Disc Diameter (mm): 185
Clutch Disc Spline Count: 23
Clutch Disc Spline Diameter (mm): 26
Torque (Nm): 1060
Flywheel Step:
Design: Twin Plate
Stage:
Clamp Load:
Recommended for: Motorsport
Ring Gear Tooth count:
Additional information:
184mm Twin Plate
Suitable for:
- Mazda/RX-8/1.3 (FE103. SE3P)/2003.10-2012.06/13B-MSP 1308 Petrol 141 kW 192 BHP (2003.10 - 2012.06)
Mazda/RX-8/1.3/2003.11-2012.06/13B-MSP 1308 Petrol 158 kW 215 BHP (2003.11 - 2012.06)
Mazda/RX-8/1.3 (FE103. SE3P)/2003.10-2012.06/13B-MSP 1308 Petrol 170 kW 231 BHP (2003.10 - 2012.06)
Mazda/RX-8/1.3 (SE3P)/2003.11-2012.06/13B-MSP 1308 Petrol 177 kW 241 BHP (2003.11 - 2012.06) ,
- Write a review
Did not find your question?
Enter new question Do you have a question? Search for an answer.
| Mark | Model | Type | Engine code |
|---|---|---|---|
| Mazda | RX-8 | 1.3 (FE103. SE3P) | 13B-MSP 1308 Petrol 141 kW 192 BHP (2003.10 - 2012.06) |
| Mazda | RX-8 | 1.3 (FE103. SE3P) | 13B-MSP 1308 Petrol 170 kW 231 BHP (2003.10 - 2012.06) |
| Mazda | RX-8 | 1.3 (SE3P) | 13B-MSP 1308 Petrol 177 kW 241 BHP (2003.11 - 2012.06) |
| Mazda | RX-8 | 1.3 | 13B-MSP 1308 Petrol 158 kW 215 BHP (2003.11 - 2012.06) |
