REDARC monocrystalline fixed solar panel, 180 W, black frame

The REDARC monocrystalline fixed solar panel, 180 W, is designed for fixed installation, typically on the roof of caravans, RVs and motorhomes, as well as some camper trailers and 4x4 vehicles. Its monocrystalline cells are highly efficient. A tempered glass coating and a sturdy anodised aluminium frame let it withstand harsh road conditions and extreme weather. For its power output, the panel is lighter and has a smaller footprint. It works with REDARC solar regulators and solar accessories. Each panel is tested at the time of manufacture to conform to CE standards, so its output matches its specification.

Features:

• High-efficiency monocrystalline construction
• Anodised aluminium frame, black
• Robust tempered glass coating
• Quality MC4-style connectors for easy installation
• Reduced weight and smaller footprint for its power output
• Suitable for outdoor use
• Tested at manufacture to conform to CE standards

Specifications:

• Power: 180 W
• Solar cell type: Monocrystalline
• Open circuit voltage: 27.6 V
• Max. power voltage: 23.4 V
• Short circuit current: 8.2 A
• Max. power current: 7.7 A
• Operating temperature: –40 °C to +85 °C
• Frame: Anodised aluminium, black
• Connector type: MC4-style
• Cable length: 900 mm
• Dimensions: 1430 x 670 x 35 mm
• Weight: 10.4 kg
