PEDDERS Heavy Duty front coil spring for Citroën/Peugeot/Fiat/Opel/Toyota/Vauxhall, 240125B (standard height)

The Heavy Duty range is made for vehicles that carry a permanent load, tow or have heavy accessories: it holds the ride height under load and stops the suspension bottoming out.

PEDDERS springs are made to ISO 9001 with a loaded-height tolerance of only ±2 mm, so the car sits level and both sides match. The rate is tuned to limit body roll and camber change in a corner without being so stiff that the wheel skips over bumps. The springs are hot coiled, oil quenched, tempered, shot peened and powder coated.

• Range: Heavy Duty
• Axle: front
• Version: standard height
• Spring rate: 11.03 kg/mm
• Free height: 325 mm
• Load at ride height: 680 kg
• Height at ride load: 245 mm

Suitable for:

• Citroën Jumper / Relay 30 Chassis Cab - 12Q 30 (2006-)
• Citroën Jumper / Relay 30 Chassis Cab - 12Q 30 (2006-2011)
• Citroën Jumper / Relay 30 Van & Minibus - 12Q 30 (2006-)
• Citroën Jumper / Relay 33 Chassis Cab - 14Q 33 (2006-)
• Citroën Jumper / Relay 33 Chassis Cab - 14Q 33 (2006-2011)
• Citroën Jumper / Relay 33 Van & Minibus - 14Q 33 (2006-)
• Citroën Jumper / Relay 35 Chassis Cab - 16 QL 35 (2006-)
• Citroën Jumper / Relay 35 Chassis Cab - 16 QL 35 (2006-2011)
• Citroën Jumper / Relay 35 Van & Minibus - 16 QL 35 (2006-)
• Fiat Ducato 30 Chassis Cab X250 Q11 (2006-)
• Fiat Ducato 30 Van & Minibus X250 Q11 (2006-)
• Fiat Ducato 33 Chassis Cab X250 Q15 (2006-)
• Fiat Ducato 33 Van & Minibus X250 Q15 (2006-)
• Fiat Ducato 35 Chassis Cab X250 Q17 (2006-)
• Fiat Ducato 35 Maxi Chassis Cab X250 Q17H (2006-)
• Fiat Ducato 35 Maxi Van & Minibus X250 Q17H (2006-)
• Fiat Ducato 35 Van & Minibus X250 Q17 (2006-)
• Opel Movano 2.2D FWD (2021-)
• Peugeot Boxer 330 Chassis Cab - 12Q (2006-)
• Peugeot Boxer 330 Chassis Cab - 12Q (2006-2011)
• Peugeot Boxer 330 Van & Minibus - 12Q (2006-)
• Peugeot Boxer 333 Chassis Cab - 14Q (2006-)
• Peugeot Boxer 333 Chassis Cab - 14Q (2006-2011)
• Peugeot Boxer 333 Van & Minibus - 14Q (2006-)
• Peugeot Boxer 335 Chassis Cab - 16 QL (2006-)
• Peugeot Boxer 335 Van & Minibus - 16 QL (2006-)
• Toyota Proace Max 2.2 D-4D FWD (2024-)
• Vauxhall Movano 2.2D FWD (2021-)
