KMI20520-1E Clutch Kit Xtreme Performance Rigid Ceramic Single Plate Incl Flywheel

Name: KMI20520-1E Clutch Kit Xtreme Performance Rigid Ceramic Single Plate Incl Flywheel
Brand: Xtreme clutch
SKU: KMI20520-1E
Price: 1337.10 EUR
Availability: OutOfStock

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

Show full description

Condition: New product

Sold out

1.337,10 € tax incl.1

Product is unavailable. Please choose other goods.

Enquiry product

Notify me

For automatic information about product status update,
click on "notify me".

Reference: KMI20520-1E

EAN: 9337467147537

Frequently bought together

-1E

The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality. The 200mm Race Clutch KitÃ¢â¬â¢s consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).

Clamping Force	1000kg
Torque Rating	900Nm
Bearing Contact Diameter	44-52mm
Bearing Load (@ 48mm)	218kg
Release Travel Required	6mm
Assembly Mass (without flywheel)	5.15kg
Disc Set Static Mass	0.9kg
Friction Thickness New	7mm (0.275")
Friction Thickness Worn	5.7mm (0.235")

Product Features:

Rigid driven disc
Push type billet alloy cover
4140 Chromoly pressure plate
Hardened steel wear posts
Low inertia
Serviceable components
SFI certified design

Tech. Info:

Reference: KMI20520-1E

Weight: 12

Note:

Clutch Disc Diameter (mm): 200
Clutch Disc Spline Count: 20
Clutch Disc Spline Diameter (mm): 22.4
Torque (Nm):
Flywheel Step:
Design: Single Plate
Stage: Track Use Only
Clamp Load: 1100Kg
Recommended for: Motorsport
Ring Gear Tooth count:
Additional information:
