KMI22001-1C Clutch Kit Xtreme Performance Heavy Duty Cushioned Ceramic 370Nm

Xtreme Performance - Cushioned Ceramic kit /-1CRecommended for: Motorsport Applications

These kits are available with cushioned ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

Specifications:

• Torque capacity 370Nm
• Clamp load Increased over standard
• Cushioned Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The Xtreme Clutch cushioned ceramic range of upgrades offers exceptional heat capacity and torque capacity whilst providing cushioning between the friction surfaces of the disc, ensuring excellent driveability. The discs still retain the sprung hub that helps to reduce shock loading. These kits are commonly used in vehicles that are used on the road occasionally but mainly focused on track applications.

Xtreme PerformanceAt Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

What's in the Box?Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Tech. Info:

Reference: KMI22001-1C

Weight: 7.16

Note:

Clutch Disc Diameter (mm): 215
Clutch Disc Spline Count: 23
Clutch Disc Spline Diameter (mm): 26.3
Torque (Nm): 370
Flywheel Step: 0
Design: Single Plate
Stage: Stage 2
Clamp Load:
Recommended for: Track - Stage 2
Ring Gear Tooth count:
Additional information:

Single Plate

Suitable for:

- Mitsubishi/L200/2.0 4WD/1981.07-1982.09/4G52 1995 Petrol 66 kW 90 BHP (1981.07 - 1982.09)
Mitsubishi/L200/2.0/1981.10-1982.09/4G52 1995 Petrol 66 kW 90 BHP (1981.10 - 1982.09)
Mitsubishi/L200/2.0/1982.10-1986.10/4G52 1995 Petrol 66 kW 90 BHP (1982.10 - 1986.10)
Mitsubishi/L200/2.0 4WD/1982.10-1986.10/4G52 1995 Petrol 66 kW 90 BHP (1982.10 - 1986.10)
Mitsubishi/L300/2.0/1994.06-1996.05/4G63 (SOHC 16V) 1997 Petrol 78 kW 106 BHP (1994.06 - 1996.05)
Mitsubishi/L300/2.0 GLS (P03W. P13W)/1994.06-1996.05/4G63 (SOHC 16V) 1997 Petrol 78 kW 106 BHP (1994.06 - 1996.05)
Mitsubishi/Delica / Space Gear/2.0/1996.05-2004.05/4G63 (SOHC 16V) 1997 Petrol 78 kW 106 BHP (1996.05 - 2004.05)
Mitsubishi/L300/2.0 i (P00W. P03W. P13W)/1994.06-1998.10/4G63 (SOHC 16V) 1997 Petrol 83 kW 113 BHP (1994.06 - 1998.10)
Mitsubishi/Delica / Space Gear/2.0/1996.05-2004.05/4G63 (SOHC 16V) 1997 Petrol 85 kW 116 BHP (1996.05 - 2004.05)
Mitsubishi/L300/2.0/1986.11-1988.07/4G63 (SOHC 8V) 1997 Petrol 66 kW 90 BHP (1986.11 - 1988.07)
Mitsubishi/L300/2.0 (P03W. P13W)/1986.11-2004.05/4G63 (SOHC 8V) 1997 Petrol 66 kW 90 BHP (1986.11 - 2004.05)
Mitsubishi/L300/2.0 4WD/1982.06-1986.10/4G63 (SOHC 8V) 1997 Petrol 74 kW 101 BHP (1982.06 - 1986.10)
Mitsubishi/L300/2.0 DL 4WD/1984.08-1986.10/4G63 (SOHC 8V) 1997 Petrol 74 kW 101 BHP (1984.08 - 1986.10)
Mitsubishi/L300/2.0 (P23V. P03V. P13V)/1994.06-1996.05/4G63 (SOHC 8V) 1997 Petrol 78 kW 106 BHP (1994.06 - 1996.05)
Mitsubishi/L300/2.0 DL/1982.06-1985.08/4G63 (SOHC 8V), G63B 1997 Petrol 66 kW 90 BHP (1982.06 - 1985.08)
Mitsubishi/L300/2.0 (P03V. P13V)/1986.11-1996.05/G63B 1997 Petrol 64 kW 87 BHP (1986.11 - 1996.05) ,
