KNI18520-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel

Name: KNI18520-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel
Brand: Xtreme clutch
SKU: KNI18520-3E
Price: 2231.70 EUR
Availability: OutOfStock

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

Show full description

Condition: New product

2.231,70 € tax incl.1

Sold out

In stock: 0 psc

Product is unavailable. Please choose other goods.

For automatic information about product status update,
click on "notify me".

Enquiry product

Notify me

Reference: KNI18520-3E

EAN: 9337467178647

Frequently bought together

-3E

The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.

Â	Ø184mm Light Diaphragm (2.6mm)	Ø184mm Heavy Diaphragm (2.8mm)
Clamping Force	950kg	1080kg
Torque Rating	1600Nm	1820Nm
Bearing Contact Diameter	44-52mm	44-52mm
Bearing Load (@ 48mm)	210kg	260kg
Release Travel Required	5mm	5mm
Assembly Mass (without flywheel)	4.75kg	4.75kg
Disc Set Static Mass	1.2kg
Friction Thickness New	2.6mm (0.103")	2.6mm (0.103")
Friction Thickness Worn	2.36mm (0.093")	2.36mm (0.093")

Product Features:

Push type billet alloy cover
4140 Chromoly pressure plate
Hardened steel wear posts
High and low ratio pressure plate options
Low inertia
Serviceable components
SFI certified design

Tech. Info:

Reference: KNI18520-3E

Weight: 11.4

Note:

Clutch Disc Diameter (mm): 184
Clutch Disc Spline Count: 24
Clutch Disc Spline Diameter (mm): 25.4
Torque (Nm): 1830
Flywheel Step: +2.5mm
Design: Triple Plate
Stage: Multiplate - track use only
Clamp Load: 900Kg
Recommended for: Motorsport
Ring Gear Tooth count:
Additional information:

184mm Triple Plate

Suitable for:

- Nissan/Skyline/R32 | 2.0/1990.01-1993.01/RB20DET 1998 Petrol 153 kW 208 BHP (1990.01 - 1993.01)
Nissan/Skyline/R32 | 2.0 Turbo/1989.03-1993.06/RB20DET 1998 Petrol 158 kW 215 BHP (1989.03 - 1993.06)
Nissan/Skyline/R32 | 2.0 Turbo 4x4/1989.03-1993.06/RB20DET 1998 Petrol 158 kW 215 BHP (1989.03 - 1993.06)
Nissan/Skyline/R32 | 2.0/1990.01-1993.01/RB20DET 1998 Petrol 160 kW 218 BHP (1990.01 - 1993.01)
Nissan/Skyline/R32 | 2.0 AWD/1990.01-1993.01/RB20DET 1998 Petrol 160 kW 218 BHP (1990.01 - 1993.01)
Nissan/Skyline/R32 | 2.5/1989.03-1993.06/RB25DE 2498 Petrol 132 kW 179 BHP (1989.03 - 1993.06)
Nissan/Skyline/R33 | 2.5/1993.07-1998.05/RB25DE 2498 Petrol 140 kW 190 BHP (1993.07 - 1998.05)
Nissan/Skyline/R33 | 2.5 4x4/1993.07-1998.05/RB25DE 2498 Petrol 140 kW 190 BHP (1993.07 - 1998.05)
Nissan/Skyline/R34 | 2.5/1998.06-2000.07/RB25DEH 2498 Petrol 147 kW 200 BHP (1998.06 - 2000.07)
Nissan/Skyline/R34 | 2.5 4x4/1998.06-2000.07/RB25DEH 2498 Petrol 147 kW 200 BHP (1998.06 - 2000.07)
Nissan/Skyline/R33 | 2.5/1994.01-2000.07/RB25DET 2498 Petrol 184 kW 250 BHP (1994.01 - 2000.07)
Nissan/Skyline/R32 | 2.6 Twin Turbo 4x4/1989.04-1993.06/RB26DETT 2569 Petrol 206 kW 280 BHP (1989.04 - 1993.06)
Holden/Calais/VL | 3.0 EFi/1986.03-1988.09/RB30E 2962 Petrol 114 kW 155 BHP (1986.03 - 1988.09)
Holden/Commodore/VL | 3.0 EFi/1986.03-1988.09/RB30E 2962 Petrol 114 kW 155 BHP (1986.03 - 1988.09)
Nissan/Skyline/R31 | 3.0/1986.07-1990.12/RB30E 2962 Petrol 117 kW 159 BHP (1986.07 - 1990.12)
Holden/Calais/VL | 3.0 EFi Turbo/1986.01-1988.08/RB30ET 2962 Petrol 150 kW 204 BHP (1986.01 - 1988.08)
Holden/Commodore/VL | 3.0 EFi Turbo/1986.01-1988.08/RB30ET 2962 Petrol 150 kW 204 BHP (1986.01 - 1988.08)
Nissan/Skyline/R31 | 3.0/1985.08-1989.03/RB30S 2962 Petrol 105 kW 143 BHP (1985.08 - 1989.03) ,

Write a review

Be the first to write your review !

Did not find your question?

Enter new question

Do you have a question? Search for an answer.

Mark	Model	Type	Engine code
Holden	Calais	VL 3.0 EFi	RB30E 2962 Petrol 114 kW 155 BHP (1986.03 - 1988.09)
Holden	Calais	VL 3.0 EFi Turbo	RB30ET 2962 Petrol 150 kW 204 BHP (1986.01 - 1988.08)
Holden	Commodore	VL 3.0 EFi	RB30E 2962 Petrol 114 kW 155 BHP (1986.03 - 1988.09)
Holden	Commodore	VL 3.0 EFi Turbo	RB30ET 2962 Petrol 150 kW 204 BHP (1986.01 - 1988.08)
Nissan	Skyline	R31 3.0	RB30E 2962 Petrol 117 kW 159 BHP (1986.07 - 1990.12)
Nissan	Skyline	R31 3.0	RB30S 2962 Petrol 105 kW 143 BHP (1985.08 - 1989.03)
Nissan	Skyline	R32 2.0 Turbo 4x4	RB20DET 1998 Petrol 158 kW 215 BHP (1989.03 - 1993.06)
Nissan	Skyline	R32 2.0 Turbo 4x4	RB20DET 1998 Petrol 160 kW 218 BHP (1990.01 - 1993.01)
Nissan	Skyline	R32 2.0 Turbo	RB20DET 1998 Petrol 153 kW 208 BHP (1990.01 - 1993.01)
Nissan	Skyline	R32 2.0 Turbo	RB20DET 1998 Petrol 158 kW 215 BHP (1989.03 - 1993.06)
Nissan	Skyline	R32 2.0 Turbo	RB20DET 1998 Petrol 160 kW 218 BHP (1990.01 - 1993.01)
Nissan	Skyline	R32 2.5	RB25DE 2498 Petrol 132 kW 179 BHP (1989.03 - 1993.06)
Nissan	Skyline	R32 2.6 Twin Turbo 4x4	RB26DETT 2569 Petrol 206 kW 280 BHP (1989.04 - 1993.06)
Nissan	Skyline	R33 2.5 4x4	RB25DE 2498 Petrol 140 kW 190 BHP (1993.07 - 1998.05)
Nissan	Skyline	R33 2.5	RB25DE 2498 Petrol 140 kW 190 BHP (1993.07 - 1998.05)
Nissan	Skyline	R33 2.5 Turbo	RB25DET 2498 Petrol 184 kW 250 BHP (1994.01 - 2000.07)
Nissan	Skyline	R34 2.5 4x4	RB25DEH 2498 Petrol 147 kW 200 BHP (1998.06 - 2000.07)
Nissan	Skyline	R34 2.5	RB25DEH 2498 Petrol 147 kW 200 BHP (1998.06 - 2000.07)
