EGR removal plug with gaskets suitable for RENAULT NISSAN X-TRAIL 2.0 dCi

The EGR valve reduces the pollutant content of the exhaust gases by allowing you to determine the amount of flue gases into the intake. However, diesel oil is very greasy, and the EGR is often blocked, consequently reducing the passage of the entire suction tract of the engine. There is a decrease of performance and increase of smoke.

This kit contains the gaskets and the plug to blank the original EGR valve.

Note : after blanking, the EGR system should be removed by software, because an error will be displayed on the dashboard



Application:

Nissan
PRIMASTAR Autobus (X83)
dCi 120 (M9R 630 M9R 692 M9R 780 M9R 786) 1995ccm 114HP/84kW 2006/09-
PRIMASTAR (X83)
2.0 dCi 115 (M9R 630 M9R 692 M9R 780 M9R 786) 1995ccm 114HP/84kW 2006/09-
QASHQAI / QASHQAI +2 I (J10, NJ10, JJ10E)
2.0 dCi (M1D M9R) 1995ccm 150HP/110kW 2007/02-2013/12
2.0 dCi all wheel drive (M1D M9R) 1995ccm 150HP/110kW 2007/02-2013/12
X-TRAIL (T31)
2.0 dCi (M9R) 1995ccm 150HP/110kW 2007/06-2013/11
2.0 dCi 4x4 (M9R 760) 1995ccm 173HP/127kW 2007/06-2013/11
2.0 dCi 4x4 (M9R) 1995ccm 150HP/110kW 2007/06-2013/11

Opel
VIVARO A Autobus (X83)
2.0 CDTI (F7, J7, A07) (M9R 630 M9R 692 M9R 780 M9R 784 M9R 786 M9R 788) 1995ccm 114HP/84kW 2006/08-
2.0 CDTI (F7, J7, A07) (M9R 780 M9R 782 M9R 786) 1995ccm 90HP/66kW 2006/08-
VIVARO A Platform (X83)
2.0 CDTI (M9R 630 M9R 780 M9R 782 M9R 786) 1995ccm 90HP/66kW 2006/01-
2.0 CDTI (M9R 630 M9R 780) 1995ccm 114HP/84kW 2006/08-
VIVARO A (X83)
2.0 CDTI (F7) (M9R 630 M9R 692 M9R 780 M9R 784 M9R 786 M9R 788) 1995ccm 114HP/84kW 2006/08-
2.0 CDTI (F7) (M9R 630 M9R 780 M9R 782 M9R 786) 1995ccm 90HP/66kW 2006/08-

Renault
ESPACE IV (JK0/1_)
2.0 dCi (JK01, JK02, JK1J, JK1K, JK1H) (M9R 740 M9R 750 M9R 814 M9R 815 M9R 858) 1995ccm 150HP/110kW 2006/01-
2.0 dCi (JK03, JK04, JK1C, JK1G, JK1J, JK1K) (M9R 760 M9R 761 M9R 762 M9R 763 M9R 812 M9R 815 M9R 859) 1995ccm 173HP/127kW 2006/01-
GRAND SCÉNIC II (JM0/1_)
2.0 dCi (JM1K) (M9R 700 M9R 721 M9R 722) 1995ccm 150HP/110kW 2005/09-2008/11
KOLEOS I (HY_)
2.0 dCi 4x4 (HY0B) (M9R 830) 1995ccm 173HP/127kW 2008/09-
LAGUNA II (BG0/1_)
2.0 dCi (BG14, BG1S) (M9R 760) 1995ccm 173HP/127kW 2006/01-2007/08
2.0 dCi (BG1T) (M9R 740) 1995ccm 150HP/110kW 2005/08-2006/08
LAGUNA II Grandtour (KG0/1_)
2.0 dCi (KG1S) (M9R 760) 1995ccm 173HP/127kW 2006/01-2007/12
2.0 dCi (KG1T) (M9R 740) 1995ccm 150HP/110kW 2005/08-2006/08
LAGUNA III (BT0/1)
2.0 dCi (BT01, BT08, BT09, BT0E, BT0K, BT12, BT1C, BT1D,... (M9R 742 M9R 744 M9R 746 M9R 748 M9R 754 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858) 1995ccm 150HP/110kW 2007/10-2015/12
2.0 dCi (BT07, BT0J, BT14, BT1A, BT1S) (M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858) 1995ccm 131HP/96kW 2007/10-2015/12
2.0 dCi (BT0M, BT0N, BT0S, BT19, BT1F) (M9R 800 M9R 806 M9R 809 M9R 815 M9R 854 M9R 857 M9R 858) 1995ccm 173HP/127kW 2008/01-2015/12
2.0 dCi GT (BT11, BT1E, BT1N) (M9R 816 M9R 820 M9R 828) 1995ccm 178HP/131kW 2008/03-2015/12
LAGUNA III Grandtour (KT0/1)
2.0 dCi (KT01, KT08, KT09, KT0K, KT12, KT1D, KT1W) (M9R 742 M9R 744 M9R 802 M9R 805 M9R 808 M9R 814 M9R 845 M9R 854 M9R 858) 1995ccm 150HP/110kW 2007/10-2015/12
2.0 dCi (KT07, KT0J, KT14, KT1A, KT1S) (M9R 742 M9R 744 M9R 802 M9R 814 M9R 854 M9R 858) 1995ccm 131HP/96kW 2007/10-2015/12
2.0 dCi (KT0M, KT0N, KT0S, KT19, KT1F) (M9R 800 M9R 806 M9R 809 M9R 815 M9R 849 M9R 854 M9R 857 M9R 858) 1995ccm 173HP/127kW 2008/01-2015/12
2.0 dCi GT (KT11, KT1E, KT1N) (M9R 816 M9R 820 M9R 828) 1995ccm 178HP/131kW 2008/03-2015/12
MEGANE II (BM0/1_, CM0/1_)
2.0 dCi (BM1K, CM1K) (M9R 700 M9R 722) 1995ccm 150HP/110kW 2005/09-2008/02
MEGANE II Coupé-Cabriolet (EM0/1_)
2.0 dCi (M9R 700 M9R 722) 1995ccm 150HP/110kW 2005/09-2009/03
MEGANE II Kombi (HP0/1_)
2.0 dCi (M9R 700 M9R 722) 1995ccm 150HP/110kW 2005/09-2009/07
MEGANE II sedan (LM0/1_)
2.0 dCi (M9R 700 M9R 722) 1995ccm 150HP/110kW 2005/09-
SCÉNIC II (JM0/1_)
2.0 dCi (JM1K) (M9R 700 M9R 721 M9R 722) 1995ccm 150HP/110kW 2005/09-2008/11
TRAFIC II Autobus (JL)
2.0 dCi 115 (M9R 692 M9R 780 M9R 782 M9R 786) 1995ccm 114HP/84kW 2006/08-
TRAFIC II Platforma (EL)
2.0 dCi 115 (EL0H) (M9R 692 M9R 780 M9R 782 M9R 786) 1995ccm 114HP/84kW 2006/08-
2.0 dCi 90 (EL0H) (M9R 780 M9R 782) 1995ccm 90HP/66kW 2006/08-
TRAFIC II (FL)
2.0 dCi 115 (FL01, FL0U) (M9R 692 M9R 780 M9R 782 M9R 786) 1995ccm 114HP/84kW 2006/08-
VEL SATIS (BJ0_)
2.0 dCi (BJ03) (M9R 760) 1995ccm 150HP/110kW 2005/08-
2.0 dCi (BJ03, BJ0B) (M9R 760 M9R 762 M9R 763) 1995ccm 173HP/127kW 2006/01-



Replacement part / OEM codes / Manufacturer note:

BLUE PRINT ADBP740016, CSV electronic parts CGR4817, CSV electronic parts CGR4817C, CSV electronic parts CGR4817R, FEBI BILSTEIN 173830, FRECCIA EGR12-162, RIDEX 1145E0053, Stark SKEGR-0770056, SWAG 33 10 1955, TOPRAN 639 167, VEMO V46-63-0010, WILMINK GROUP WG2152507 RENAULT 8200327004, RENAULT 8200691292, RENAULT 8200693739, RENAULT 8200797706
