External wastegate Turbosmart comp-gate 40

Turbosmart's Comp-Gate40 (40mm) external wastegate was designed to fit into tight engine bays while still offering superior flow and heat handling capabilities. The revolutionary actuator housing is 25% smaller than previous designs and allows for easy spring changes (from 3psi to 26psi available) with our locking cap design and gives the ability to index the cap orientation in 12 different positions.

Features:

• Direct swap for Turbosmart Gen 4 Comp-Gate 40, inlet is the same as other 38/40mm V-band wastegates
• 40mm valve size
• High temp spring combinations from 3 – 26psi supplied in the box
• 1/8”NPT ports
• V-band clamp mounting system to suit 1-3/4” OD pipe
• Locking collar for compact size and easy spring changes
• Available in Motorsport and Compressed Gas versions
• Hall Effect, Non-Contact Position Sensor Option Available

Supplied with

• Wastegate unit (pre-assembled with spring as per order)
• SS316 Valve seat
• Inlet V-Band
• Inlet SS304 weld flange
• Outlet V-Band
• Outlet SS304 weld flange
• Collar tool (master/slave)
• 17/7 PH 3, 5, 7, 14 psi spring kit (1x spring installed)
• 4x 1/8” NPT plugs (1x installed) / 2x 1/8” NPT nipples
• Sticker
• Instruction card
