Deatschwerks DWR1000 adjustable fuel pressure regulator E85 (Black)

Made from forged aluminum and can be regulated with a high level of precision from 2 to 7 bar at a flow rate of 500 liters per hour. Using AN6 and AN8 fittings, you can adapt it to any fuel system and use its 1/8" NPT port for connecting a pressure gauge.

The regulator uses a 40 mm nitrile diaphragm, which is highly resistant to wear and compatible with all types of fuel - gasoline, ethanol, E85, Methanol, etc...

Product specifications:

• Controls fuel up to 7 bar with precision and stability
• Supports a flow rate of up to 500 litres/hour
• Quad AN8 inlet (Dash 8)
• Single AN6 outlet (Dash 6)
• 1/8" NPT port for a pressure gauge
• Ø40 mm nitrile diaphragm
• Compatible with all fuels, including E85
• Product reference: 6-1000-FRB
• Anodised black finish
