REDARC BMS1230S3-EU Manager30 battery management system, 12 V, 30 A, EU plug

The REDARC Manager30 S3 is a complete battery management system for charging auxiliary batteries in recreational automotive and marine applications. It charges the auxiliary battery from AC mains, the vehicle's DC system and solar, and picks the best charge from these sources. It works with all vehicles and alternator systems, including variable voltage alternators. One unit does the work of six: a DC-DC charger for charging on the move, a mains charger, a solar regulator, a battery isolator, a load disconnect controller and a remote battery monitor.

Features:

• Multi-stage AC-DC battery charger
• Multi-stage DC-DC charger for charging from the vehicle on the move
• MPPT (Maximum Power Point Tracking) solar regulator that gets maximum power from portable solar panels, even in low light
• Green power priority: when solar power is available it is used first, and the charging current is topped up from mains or the vehicle
• Charges from multiple sources at the same time
• Dual battery isolator
• Load disconnect controller
• Remote monitor with graphical display that shows auxiliary battery information, charge status and where the charge is coming from, and lets you customise how the battery is charged
• Charges AGM, Gel, Calcium, VRLA, standard Lead Acid and Lithium (LiFePO4) batteries
• Dedicated charging profile for lithium batteries with an in-built cell management system
• Charges one or more auxiliary batteries
• Super quiet operation
• Short circuit, surge, reverse polarity and overload protection
• EU plug

Specifications:

• Output system voltage: 12 V DC
• Maximum charging voltage: 16.0 V (Calcium setting in storage mode)
• Continuous output current: 30 A
• Output power: 520 W
• Input (operating) voltage: 240 V AC / 9 – 32 V DC
• Input fuse rating: 50 A
• Output fuse rating: 40 A
• Protection: short circuit, surge, reverse polarity, overload
• AC mains plug type: EU
• Dimensions (L × W × H): 445 × 185 × 79 mm
• Weight: 5.5 kg
• Type approval: CE
