DAVIES CRAIG digital fan switch (thermal probe), 0444

Description

Designed by Davies Craig, this Digital Thermatic Fan Switch can be used with Davies Craig Thermatic Fans, EWPs and competitors' fans. It provides precise control over your cooling system by sensing air or coolant temperature.

The switch can run 1 or 2 fans and is suitable for 12V or 24V applications.

The dual fan logic ensures that Fan #1 starts at the set temperature, while Fan #2 activates 10 seconds later to manage peak cooling loads efficiently.

Features and versatility

• Flexible sensor fitment: use as an air probe (radiator fins) or coolant sensor (with adapter DC0409)
• Extended wiring: total sensor wire length of 320cm (for batches post Dec-2021)
• IP66 rated: protected from total dust ingress and high-pressure water jets
• Temperature range: adjustable from 40°C to 110°C (104°F to 230°F)
• 24V compatible: the kit is 12V standard; simply swap to 24V relays (DC10534) for 24V systems

Specifications

• Number of fans: 1 or 2
• Voltage: 12V (24V with separate relays DC10534)
• Temperature range: 40°C to 110°C (104°F to 230°F)
• Sensing: air or coolant temperature
• Protection rating: IP66
• Sensor wire length: 320cm (batches post Dec-2021)
• Fan #2 delay: 10 seconds

Package Contents

• 1× Digital Fan Switch (IP66)
• 1× Thermal Sensor Probe
• 1× Mounting Kit for Thermal Sensor Probe
• 4× Ring Terminals (6mm) & Wire Joiners
• 3× Self Tap Screws & Instructions

Warning

The kit is supplied for 12V. 24V applications require separate 24V relays (DC10534).
